Disclaimer:
Please note that due to the large size of the 550x1450 Arctic Tern Windows, these items will be shipped via freight to ensure they arrive in good, usable, and undamaged condition. If you do not have access to a forklift or a loading dock at the delivery location, an additional charge may apply for liftgate service. We will reach out if additional charges apply to your order. If you have any questions or concerns, please feel free to reach out to us at info@ternoverland.com.
Arctic Tern Windows
Our windows are designed for adventurers who demand strength, performance, and reliability—combining cutting-edge materials, innovative design, and rugged construction.
UNMATCHED QUALITY AND DESIGN
Every Arctic Tern Window is built from premium, globally sourced components. Crafted from genuine G.E. Lucite Perspex, our dual-pane European acrylic maintains exceptional clarity even after 10 years of full sun exposure.
A top-tier powder coating ensures enduring protection against the elements, while precise assembly meets strict European ECE regulations and is DOT-certified for North America. Select sizes can even serve as emergency exits.
CLASSIC & FLAT WINDOW OPTIONS
Choose between our Classic and Flat designs to match your build style.
- Classic: Bright, open interior with a raised profile
- Flat: Sleek, modern exterior with dark gray tint for privacy and glare control
Both options include the integrated blind and screen system.
INTEGRATED BLIND & SCREEN SYSTEM
Each window includes a dual-function assembly available in white or black:
- Fine mesh insect screen
- Blackout blind with reflective exterior
These can be used independently or together, creating a second dead air space for enhanced thermal insulation in cold conditions.
PERFORMANCE & DURABILITY
- Dual-pane European acrylic construction
- Lightweight design (~60% the weight of glass)
- High impact resistance (won’t shatter)
- Excellent thermal insulation for all-season comfort
- High-quality rubber seals for weather-tight protection
FLEXIBLE INSTALLATION
- Multiple sizes available to fit a wide range of builds
- Push-button locking handles with secure vent position
- Compatible with multiple wall thicknesses
MULTI-POSITION STRUTS
- 10 and 35 degree opening settings for the 300mm size windows
- 20, 40, and 60 degree opening settings for all other size windows
- Cam Lock Struts (available separately) allow opening settings at any angle, and allows window to be opened to 90 degrees
WHY ACRYLIC
- Lightweight: ~50% lighter than glass
- Thermally efficient: Over 4× better insulation
- Impact resistant: 11–15× stronger than glass
- Non-shattering: Safer for off-grid travel
SERVICE & SUPPORT YOU CAN TRUST
One-year warranty. U.S.-based support. Fully stocked replacement parts in Prescott, Arizona.
2026 Tern Overland Classic & Flat Window Dimensions
| Name | Dimension | Orientation* | Lbs | Cut Hole | Overall | Blind/Screen |
| 300x500 | 11 3/4" x 19 5/8" | C & F, WH & AB, 4 IFRs | 10 | 11 7/8" x 19 3/4" | 13" x 20 7/8" | 14 3/4" x 21 3/8" |
| 300x700 | 11 3/4" x 27 1/2" | C & F, WH & AB, 4 IFRs | 11 | 11 7/8" x 27 5/8" | 13" x 28 3/4" | 14 3/4" x 29 1/4" |
| 300x1100 | 11 3/4" x 43 1/4" | C & F, WH & AB, 4 IFRs | 13 | 11 7/8"x 43 3/8" | 13" x 44 1/2" | 14 3/4" x 45" |
| 450x500 | 17 3/4" x 19 5/8" | C & F, WH & AB, 4 IFRs | 12 | 17 7/8" x 19 3/4" | 18 7/8" x 20 7/8" | 20 5/8" x 21 3/8" |
| 450x610 | 17 3/4" x 24" | C & F, WH & AB, 4 IFRs | 13 | 17 7/8" x 24 1/8" | 18 7/8" x 25 1/4" | 20 5/8" x 25 5/8" |
| 450x900 | 17 3/4" x 35 3/8" | C & F, WH & AB, 4 IFRs | 18 | 17 7/8" x 35 1/2" | 18 7/8" x 36 5/8" | 20 5/8" x 37 1/8" |
| 450x1100 | 17 3/4" x 43 1/4" | C & F, WH & AB, 4 IFRs | 21 | 17 7/8" x 43 3/8" | 18 7/8" x 44 1/2" | 20 5/8" x 45" |
| 500x300 | 19 5/8" x 11 3/4" | C & F, WH & AB, 4 IFRs | 10 | 19 3/4" x 11 7/8" | 20 7/8" x 13" | 22 5/8" x 13 1/2" |
| 550x700 | 21 5/8" x 27 1/2" | C & F, WH & AB, 4 IFRs | 17 | 21 3/4" x 27 5/8" | 22 7/8" x 28 3/4" | 24 5/8" x 29 1/4" |
| 550x900 | 21 5/8" x 35 3/8" | C & F, WH & AB, 4 IFRs | 20 | 21 3/4" x 35 1/2" | 22 7/8" x 36 5/8" | 24 5/8" x 37 1/8" |
| 550x1100 | 21 5/8" x 43 1/4" | C & F, WH & AB, 4 IFRs | 23 | 21 3/4" x 43 3/8" | 22 7/8" x 44 1/2" | 24 5/8" x 45" |
| 550x1450 | 21 5/8" x 57 1/8" | C & F, WH & AB, 4 IFRs | 29 | 21 3/4" x 57 1/4" | 22 7/8" x 58 1/4" | 24 5/8" x 58 3/4" |
Note: Images are for illustration purposes only. Images MAY NOT represent the product listed. Please contact Customer Service with any questions or concerns: (928) 642-3459.
